HIKVISION DS-7604NI-K1 User Manual

Network Video Recorder User Manual
168
3) Select the font size to small, medium or large.
4) Set the overlay time of the characters. The value ranges 5 -3600 sec.
5) Set the delay time of POS event. The value ranges 5 -3600 sec. When the device has not
received the POS message over the defined delay time, the transaction is finished.
6) (optional) Check the checkbox to enable the POS Overlay in Live View. When this
feature is enabled, the POS information can be overlain on the live view image.
7) Select the font color for the characters.
Figure 9-11 Overlay Character Settings
You can adjust the size and position of textbox on the preview screen of POS settings interface by
dragging the frame.
Step 7 Click Apply to activate the settings.
Step 8 (Optional) You can click the Copy button to copy the current settings to other POS (s).
Figure 9-12 Copy POS Settings

HIKVISION DS-7604NI-K1 Specifications

General

PTZ control	Yes
Display modes	Full screen, Live view, Playback, Split scren
Maximum frame rate	60 fps
Maximum resolution	3840 x 2160 pixels
Throughput data rate	40 Mbit/s
Video input channels	4 channels
Supported resolutions	3840 x 2160, 3840 x 2160, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video formats supported	H.264, H.264+, H.265, MPEG4
Resolution at capture speed	1280x720@60fps, 1920x1080@60fps, 3840x2160@30fps
Built-in display	No
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, DHCP, HIK Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD capacity	0 GB
HDD interface	Serial ATA
Maximum storage capacity	6 TB
Number of HDDs installed	0
Product color	Black
Rack capacity	1U
Operating temperature (T-T)	-10 - 55 °C
Output voltage	12 V

Weight and Dimensions

Depth	225 mm
Width	260 mm
Height	48 mm
Weight	1000 g
