Network Video Recorder User Manual
204
If you set the port number as 443 and the IP address is 192.0.0.64, you may access the device by
inputting https://192.0.0.64:443 via the web browser.
The HTTPS port can be only configured through the web browser.
Step 1 Open web browser, input the IP address of device, and the web server will select the
language automatically according to the system language and maximize the web browser.
Step 2 Input the correct user name and password, and click Login button to log in the device.
Step 3 Enter the HTTPS settings interface.
Step 4 Configuration > Remote Configuration > Network Settings > HTTPS
Step 5 Create the self-signed certificate or authorized certificate.
Figure 12-13 HTTPS Settings
OPTION 1: Create the self-signed certificate
1) Click the Create button to create the following dialog box.
Figure 12-14 Create Self-signed Certificate
2) Enter the country, host name/IP, validity and other information.

Table of Contents

Other manuals for HIKVISION DS-7604NI-K1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7604NI-K1 and is the answer not in the manual?

HIKVISION DS-7604NI-K1 Specifications

General IconGeneral
PTZ controlYes
Display modesFull screen, Live view, Playback, Split scren
Maximum frame rate60 fps
Maximum resolution3840 x 2160 pixels
Throughput data rate40 Mbit/s
Video input channels4 channels
Supported resolutions3840 x 2160, 3840 x 2160, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video formats supportedH.264, H.264+, H.265, MPEG4
Resolution at capture speed1280x720@60fps, 1920x1080@60fps, 3840x2160@30fps
Built-in displayNo
USB 2.0 ports quantity2
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN (RJ-45) ports1
Supported network protocolsTCP/IP, DHCP, HIK Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD capacity0 GB
HDD interfaceSerial ATA
Maximum storage capacity6 TB
Number of HDDs installed0
Product colorBlack
Rack capacity1U
Operating temperature (T-T)-10 - 55 °C
Output voltage12 V
Weight and Dimensions IconWeight and Dimensions
Depth225 mm
Width260 mm
Height48 mm
Weight1000 g
