HIKVISION DS-7604NI-K1 User Manual

Network Video Recorder User Manual
69

The PoE is enabled with the short network cable mode (OFF) by default.

The bandwidth of IP camera connected to the PoE via long network cable (100 - 300 meters)
cannot exceed 6 MP.

The allowed max. long network cable may be less than 300 meters depending on different
IP camera models and cable materials.

When the transmission distance reaches 100 to 250 meters, you must use the CAT5E or
CAT6 network cable to connect with the PoE interface.

When the transmission distance reaches 250 to 300 meters, you must use the CAT6
network cable to connect with the PoE interface.

Refer to the Appendix 18.5.3 List of IP Cameras Connected to PoE by Long Network Cable
(100 - 300 m) for the list of IP cameras.
You can check the connecting status and power information of POE channel on the interface.
Step 3 Click Back to finish the settings.

HIKVISION DS-7604NI-K1 Specifications

General

PTZ control	Yes
Display modes	Full screen, Live view, Playback, Split scren
Maximum frame rate	60 fps
Maximum resolution	3840 x 2160 pixels
Throughput data rate	40 Mbit/s
Video input channels	4 channels
Supported resolutions	3840 x 2160, 3840 x 2160, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video formats supported	H.264, H.264+, H.265, MPEG4
Resolution at capture speed	1280x720@60fps, 1920x1080@60fps, 3840x2160@30fps
Built-in display	No
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, DHCP, HIK Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD capacity	0 GB
HDD interface	Serial ATA
Maximum storage capacity	6 TB
Number of HDDs installed	0
Product color	Black
Rack capacity	1U
Operating temperature (T-T)	-10 - 55 °C
Output voltage	12 V

Weight and Dimensions

Depth	225 mm
Width	260 mm
Height	48 mm
Weight	1000 g
