Network Video Recorder Quick Start Guide
23
3.10 Recording Settings
Before you start:
Make sure that the disk has already been installed. If not, please install a disk and initialize it. You
may refer to the user manual for detailed information.
Purpose:
Two kinds of record types are introduced in the following section, including Instant Record and
All-day Record. And for other record types, you may refer to the user manual for detailed
information.
After rebooting all the manual records enabled are canceled.
Step 1 On the live view window, right lick the window and move the cursor to the Start Recording
option, and select Continuous Record or Motion Detection Record on your demand.
Figure 3-11 Start Recording from Right-click Menu
Step 2 Click the Yes button in the pop-up Attention message box to confirm the settings. All the
channels will start to record in the selected mode.
3.11 Playback
The recorded video files on the hard disk can be played back in the following modes: instant
playback, all-day playback for the specified channel, and playback by
normal/event/smart/tag/sub-periods/external file search.
Step 1 Enter playback interface.
Click Menu>Playback or from the right-click menu
Step 2 Check the checkbox of channel(s) in the channel list and then double-click to select a date on
the calendar.
Step 3 You can use the toolbar in the bottom part of Playback interface to control playing progress.

Other manuals for HIKVISION DS-7608NI-Q2/8P

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7608NI-Q2/8P and is the answer not in the manual?

HIKVISION DS-7608NI-Q2/8P Specifications

General IconGeneral
DHCP clientYes
Input bandwidth80 Mbit/s
Maximum frame rate60 fps
Maximum resolution3840 x 2160 pixels
Alarm input channels1
Video input channels8 channels
Supported resolutions1024 x 768, 1280 × 720, 1280 × 1024, 1920 × 1080, 1600 × 1200, 3840 × 2160
Video recording modes720p, 1080p
Wi-FiNo
HDD capacity2000 GB
HDD interfaceSerial ATA
Maximum storage capacity16 TB
Number of HDDs supported2
Networking standardsIEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports9
Supported network protocolsTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
Power over Ethernet (PoE) ports quantity8
Product colorBlack
Rack capacity1U
LED indicatorsLAN, Power, Status
AC input voltage100 - 240 V
Power consumption (typical)15 W
Total Power over Ethernet (PoE) budget80 W
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth315 mm
Width385 mm
Height52 mm
Weight3000 g
