HIKVISION DS-7608NI-Q2/8P Quick Start Guide

Network Video Recorder Quick Start Guide
5
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Safety Instructions
 Proper configuration of all passwords and other security settings is the responsibility of the
installer and/or end-user.
 In the use of the product, you must be in strict compliance with the electrical safety
regulations of the nation and region. Please refer to technical specifications for detailed
information.
 Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power
Source with 100~240 VAC or 12 VDC according to the IEC60950-1 standard. Please refer to
technical specifications for detailed information.
 Do not connect several devices to one power adapter as adapter overload may cause
over-heating or a fire hazard.
 Please make sure that the plug is firmly connected to the power socket.
 If smoke, odor or noise rise from the device, turn off the power at once and unplug the power
cable, and then please contact the service center.
 If the POE ports of device do not comply with Limited Power Source, the additional equipment
connected to POE ports shall have fire enclosure.
 The USB interface of the /P devices can be connected with the mouse and U-flash disk storage
device only.
Preventive and Cautionary Tips
Before connecting and operating your device, please be advised of the following tips:
 Ensure unit is installed in a well-ventilated, dust-free environment.
 Unit is designed for indoor use only.
 Keep all liquids away from the device.
Symbol
Description
Provides additional information to emphasize or supplement
important points of the main text.
Indicates a potentially hazardous situation, which if not avoided,
could result in equipment damage, data loss, performance
degradation, or unexpected results.
Indicates a hazard with a high level of risk, which if not avoided, will
result in death or serious injury.

HIKVISION DS-7608NI-Q2/8P Specifications

General

DHCP client	Yes
Input bandwidth	80 Mbit/s
Maximum frame rate	60 fps
Maximum resolution	3840 x 2160 pixels
Alarm input channels	1
Video input channels	8 channels
Supported resolutions	1024 x 768, 1280 × 720, 1280 × 1024, 1920 × 1080, 1600 × 1200, 3840 × 2160
Video recording modes	720p, 1080p
Wi-Fi	No
HDD capacity	2000 GB
HDD interface	Serial ATA
Maximum storage capacity	16 TB
Number of HDDs supported	2
Networking standards	IEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
Supported network protocols	TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
Power over Ethernet (PoE) ports quantity	8
Product color	Black
Rack capacity	1U
LED indicators	LAN, Power, Status
AC input voltage	100 - 240 V
Power consumption (typical)	15 W
Total Power over Ethernet (PoE) budget	80 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	315 mm
Width	385 mm
Height	52 mm
Weight	3000 g
