HIKVISION DS-7616NI-E2/16P User Manual

Network Video Recorder User Manual
126
8.5 Handling Exceptions Alarm
Purpose:
Exception settings refer to the handling action of various exceptions, e.g.
• HDD Full: The HDD is full.
• HDD Error: Writing HDD error or unformatted HDD.
• Network Disconnected: Disconnected network cable.
• IP Conflicted: Duplicated IP address.
• Illegal Login: Incorrect user ID or password.
• Record Exception: No space for saving recorded files.
• PoE Power Overload: The power consumption of the connected cameras via the PoE interface exceeds the
maximum PoE power.
PoE Power Overload is only supported by DS-7600NI-E1/4P, DS-7600NI-E2/8P and DS-7700NI-E4/P series
NVR.
Steps:
Enter Exception interface of System Configuration and handle various exceptions.
Menu> Configuration> Exceptions
Please refer to Chapter 8.6 Setting Alarm Response Actions for detailed alarm response actions.
Figure 8. 13 Exceptions Setup Interface

HIKVISION DS-7616NI-E2/16P Specifications

General

Model	DS-7616NI-E2/16P
Channel Input	16
Max. Incoming Bandwidth	160 Mbps
Video Compression	H.265+/H.265/H.264+/H.264
Decoding Format	H.265/H.264
USB Interface	2 USB 2.0
Alarm In/Out	16/4
Operating Humidity	10% to 90%
Type	Network Video Recorder
IP Video Input	Up to 16 IP cameras
Audio Compression	G.711
HDMI Output	1 HDMI
VGA Output	1
Audio Output	1
Recording Resolution	1080p/720p/4CIF/DCIF/2CIF/CIF/QCIF
Network Interface	1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
PoE Interface	16
Supported Standard	ONVIF
Power	100-240V AC
Power Supply	100 to 240 VAC, 50 to 60 Hz
Operating Temperature	-10°C to +55°C (14°F to 131°F)
Weight	3.5 kg
Synchronous Playback	16
Capability	16-ch
