HIKVISION DS-7616NI-E2/16P User Manual

Network Video Recorder User Manual
31
2.2 Setting Admin Password
Purpose:
For the first-time access, you need to activate the device by setting an admin password. No operation is allowed
before activation.
Steps:
1. Input the same password in the text field of Create New Password and Confirm New Password.
Figure 2. 3 Settings Admin Password
STRONG PASSWORD RECOMMENDED–We highly recommend you create a strong password of your
own choosing (Using a minimum of 8 characters, including at least three of the following categories: upper case
letters, lower case letters, numbers, and special characters.) in order to increase the security of your product.
And we recommend you reset your password regularly, especially in the high security system, resetting the
password monthly or weekly can better protect your product.
2. Click OK to save the password and activate the device.
For the old version device, if you update it to the new version, the following dialog box will pop up once the
device starts up. You can click YES and follow the wizard to set a strong password.
Figure 2. 4 Warning

HIKVISION DS-7616NI-E2/16P Specifications

General

Model	DS-7616NI-E2/16P
Channel Input	16
Max. Incoming Bandwidth	160 Mbps
Video Compression	H.265+/H.265/H.264+/H.264
Decoding Format	H.265/H.264
USB Interface	2 USB 2.0
Alarm In/Out	16/4
Operating Humidity	10% to 90%
Type	Network Video Recorder
IP Video Input	Up to 16 IP cameras
Audio Compression	G.711
HDMI Output	1 HDMI
VGA Output	1
Audio Output	1
Recording Resolution	1080p/720p/4CIF/DCIF/2CIF/CIF/QCIF
Network Interface	1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
PoE Interface	16
Supported Standard	ONVIF
Power	100-240V AC
Power Supply	100 to 240 VAC, 50 to 60 Hz
Operating Temperature	-10°C to +55°C (14°F to 131°F)
Weight	3.5 kg
Synchronous Playback	16
Capability	16-ch
