Network Video Recorder User Manual
179
12.2 Managing Network HDD
Purpose:
You can add the allocated NAS or disk of IP SAN to NVR, and use it as network HDD. Up to 8
network disks can be added.
Step 1 Enter the HDD Information interface.
Menu > HDD>General
Figure 12-6 HDD Information Interface
Step 2 Click the Add button to enter the Add NetHDD interface, as shown in Figure 12-7.
Figure 12-7 HDD Information Interface
Step 3 Add the allocated NetHDD.
Step 4 Select the type to NAS or IP SAN.
Step 5 Configure the NAS or IP SAN settings.
Add NAS disk:
1) Enter the NetHDD IP address in the text field.
2) Click the Search button to search the available NAS disks.
3) Select the NAS disk from the list shown below.
4) Or you can just manually enter the directory in the text field of NetHDD Directory.
5) Click the OK button to add the configured NAS disk.

Table of Contents

Other manuals for HIKVISION DS-7616NI-Q1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7616NI-Q1 and is the answer not in the manual?

HIKVISION DS-7616NI-Q1 Specifications

General IconGeneral
Two-way talkYes
Input bandwidth160 Mbit/s
Output bandwidth80 Mbit/s
Maximum resolution4096 x 2160 pixels
Video input channels16 channels
Supported resolutions4096 x 2160, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720
Video recording modes720p, 1080p
Audio formats supportedG.711 A-law, G.711 μ-law, G.726
Video formats supportedH.264, H.264+, H.265, H.265+, MPEG4
Resolution at capture speed1280x720@60fps, 1920x1080@60fps, 3840x2160@30fps
CertificationFCC Part 15 Subpart B, ANSI C63.4-2014 CE EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035:
Product colorBlack
Rack capacity1U
Audio RCA outputs1
USB 2.0 ports quantity2
Ethernet LAN data rates10, 100, 1000 Mbit/s
Supported network protocolsTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
HDD capacity- GB
HDD interfaceSATA
Maximum storage capacity8 TB
Number of HDDs installed0
Wi-FiNo
Output voltage12 V
Power consumption (typical)10 W
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth240 mm
Width320 mm
Height48 mm
Weight1000 g
