HIKVISION DS-8600NXI-I8/S Series User Manual

Network Video Recorder User Manual
96
Note
If the engine has been bound with channel(s), switching engine working mode will unbind the
engine and channel(s), and cancel the related smart event of the channel.
3. Click Apply to save the settings.
6.2 Face Picture Comparison
The device supports the face picture comparison alarm and face capture for the connected camera
based on face recognition feature.
Go to Smart Analysis → Engine Settings → Engine Configuration. Configure at least one engine
usage as Facial Recognition. Refer to Engine Configuration for details.
Note
The chapter is only available for certain models.
6.2.1 Face Grading Configuration
Face grading is used for face picture selection. According to pupil distance, tilt angle and pan
angle, it only uses face pictures which satisfy grading requirement for analysis. Larger pupil
distance, smaller tilt and pan angle, better it would be for analysis.
Steps
1. Go to Smart Analysis → Engine Settings → Face Grading.
Figure 6-2 Face Grading
2. Check Enable Face Grading.
3. Set Pupil Distance, Tilt Angle, and Pan Angle.
Pupil Distance

HIKVISION DS-8600NXI-I8/S Series Specifications

General

Model	DS-8600NXI-I8/S
Video Compression	H.265+/H.265/H.264+/H.264
IP Video Input	Up to 32 channels
Input Channels	32
SATA	8 SATA interfaces
Network Interface	2 x 10/100/1000 Mbps Ethernet ports
Alarm Input	16
Alarm Output	4
Power Supply	AC 100-240V, 50/60Hz
Consumption (without HDD)	≤ 40 W
Operating Humidity	10% to 90% (non-condensing)
Category	Network Video Recorder
Recording Resolution	Up to 12MP
Video Output	HDMI, VGA
Audio Output	1 channel output
Audio Input	1 (RCA)
HDD Slots	8
HDD Capacity	Up to 10TB per HDD
Max HDD Capacity	80 TB (8 × 10 TB)
RAID Type	RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
Alarm In	16 alarm inputs
Alarm Out	4-ch
Working Temperature	-10 °C to +55 °C (14 °F to 131 °F)
Operating Temperature	-10°C to 55°C
Dimensions (W × D × H)	440 mm × 450 mm × 88 mm
Weight	6.5 kg
