Network Video Recorder User Manual
154
8.3 Detecting Video Loss Alarm
Purpose:
Detect video loss of a channel and take alarm response action(s).
Step 1 Enter Video Loss interface of Camera Management and select a channel you want to detect.
Menu> Camera> Video Loss
Figure 8-9 Video Loss Setup Interface
Step 2 Set up handling action of video loss.
Check the checkbox of “Enable Video Loss Alarm”, and click button to set up handling
action of video loss.
Step 3 Set up arming schedule of the handling actions.
1) Select Arming Schedule tab to set the channel’s arming schedule.
2) Choose one day of a week and up to eight time periods can be set within each day.
3) Click Apply button to save the settings.
Time periods shall not be repeated or overlapped.

Table of Contents

Other manuals for HIKVISION DS-9608NI-I8

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-9608NI-I8 and is the answer not in the manual?

HIKVISION DS-9608NI-I8 Specifications

General IconGeneral
ModelDS-9608NI-I8
CategoryNetwork Video Recorder
Video Input Channels8
Decoding FormatH.265+/H.265/H.264+/H.264
Max Recording Resolution12MP
Synchronous Playback8 Channels
Hard Disk InterfaceSATA
Outgoing Bandwidth256 Mbps
USB Interface2 × USB 2.0
Alarm In/Out16/4
Operating Humidity10% to 90%
Video OutputHDMI, VGA
HDMI Output Resolution4K (3840 × 2160) / 30Hz
VGA Output Resolution1920 × 1080
Audio Input1 channel (RCA)
Audio Output1 channel (RCA)
HDD Slots8
Max HDD Capacity10 TB per HDD
Total Max HDD Capacity80 TB
Network Interface1 × RJ45 10/100/1000 Mbps
Power Supply100 to 240 VAC, 50 to 60 Hz
Working Temperature-10°C to +55°C
