HIKVISION DS-9608NI-I8 User Manual

Network Video Recorder User Manual
48

If you have forgotten your pattern, you can select the Forget My Pattern or Switch User
option to enter the normal login dialog box.

When the pattern you draw is different from the pattern you have configured, you should
try again.

If you have drawn the wrong pattern for more than 5 times, the system will switch to the
normal login mode automatically.
Figure 2-11 Normal Login Dialog Box
2.1.4 Login and Logout
User Login
Purpose:
If NVR has logged out, you must login the device before operating the menu and other functions.
Step 1 Select the User Name in the dropdown list.
Figure 2-12 Login Interface
Step 2 Input password.
Step 3 Click OK to log in.
When you forget the password of the admin, you can click Forget Password to reset the password.
Please refer to Chapter 2.1.5 Resetting Your Password for details.

HIKVISION DS-9608NI-I8 Specifications

General

Model	DS-9608NI-I8
Category	Network Video Recorder
Video Input Channels	8
Decoding Format	H.265+/H.265/H.264+/H.264
Max Recording Resolution	12MP
Synchronous Playback	8 Channels
Hard Disk Interface	SATA
Outgoing Bandwidth	256 Mbps
USB Interface	2 × USB 2.0
Alarm In/Out	16/4
Operating Humidity	10% to 90%
Video Output	HDMI, VGA
HDMI Output Resolution	4K (3840 × 2160) / 30Hz
VGA Output Resolution	1920 × 1080
Audio Input	1 channel (RCA)
Audio Output	1 channel (RCA)
HDD Slots	8
Max HDD Capacity	10 TB per HDD
Total Max HDD Capacity	80 TB
Network Interface	1 × RJ45 10/100/1000 Mbps
Power Supply	100 to 240 VAC, 50 to 60 Hz
Working Temperature	-10°C to +55°C
