DS-A83 Series ICVS Quick Start Guide
12
2.3 Rear Panel
2.3.1 DS-A81024S-ICVS and DS-A81024S-ICVS/Micro
Figure 2-6 Rear Panel
Table 2-2 Rear Panel Description

The button is solid green when device is running.
2
FN button

Used to position device.

The button starts/stops flashing in blue after you press it or
click the positioning button on configuration interface. Then
you press it again and it will be unlit.
3
Mute/Alarm button
When an alarm occurs in device, the button flashes in red and
buzzer sends out sound. Press it to mute buzzer.
No.
Name
No.
Name
1
Power module 1
9
FN button
2
VGA
10
Power switch
3
USB*2
11
Power module 2
4
Management LAN & USB
12
RS232
5
LAN 1 & LAN 3
13
LAN 5
6
LAN 2 & LAN 4
14
LAN 6
