2.3.4 DS-A83048S-ICVS and DS-A83048S-ICVS/Micro
Figure 2-9 Rear Panel
Table 2-5 Rear Panel Description
10
FN button
20
COM
No.
Name
No.
Name
1
Power module 1
12
LAN 5
2
BBU (optional)
13
LAN 6
3
RS-232 interface
14
Power module 2
4
LAN 1
15
LAN 3
5
LAN 2
16
LAN 4
6
USB interface 1
17
Management LAN
