4. Input Mode
4.1. HDMI PC Mode
Standard Resolution
Active Resolution
Refresh Rate Pixel Rate Aspect Ratio
H Pixels V Lines
VGA 640 480
60 Hz 25.175 MHz
4:3
75 Hz 31.5 MHz
WVGA 720 400 70 Hz 28.32 MHz 4:3
SVGA 800 600 60 Hz 40 MHz 4:3
XGA 1024 768 60 Hz 65 MHz 4:3
WXGA 1152 870 75 Hz 100 MHz 4:3
WXGA 1280 720 60 Hz 74.5 MHz 5:3
SXGA 1280 1024 60 Hz 108 MHz 5:4
UXGA 1600 900 60 Hz 108 MHz 4:3
UXGA 1680 1050 60 Hz 146.25 MHz 16:10
HD1080 1920 1080 60 Hz 148.5 MHz 16:9
Recommended resolution: 3840*2160@60Hz
4.2. HDMI video mode
Standard Resolution
Active Resolution
Refresh Rate Pixel Rate Aspect Ratio
H Pixels V Lines
3840 x 2160 P 60 Hz 3840 2160 60 Hz 594 MHz 16:9
3840 x 2160 P 30 Hz 3840 2160 30 Hz 297 MHz 16:9
3840 x 2160 P 25 Hz 3840 2160 25 Hz 297 MHz 16:9
3840 x 2160 P 24 Hz 3840 2160 24 Hz 297 MHz 16:9
1080 P 59.94/60 Hz 1920 1080 60 Hz 148.5 MHz 16:9
1080 P 50 Hz 1920 1080 50 Hz 148.5 MHz 16:9
1080 P 29.97/30 Hz 1920 1080 30 Hz 74.25 MHz 16:9
1080 P 25 Hz 1920 1080 25 Hz 74.25 MHz 16:9
1080 P 23.97/24 Hz 1920 1080 24 Hz 74.25 MHz 16:9
1080 I 59.94/60 Hz 1920 1080 60 Hz 74.25 MHz 16:9
1080 I 50 Hz 16:9 1920 1080 50 Hz 74.25 MHz 16:9
720 P 50 Hz 16:9 1280 720 50 Hz 74.25 MHz 16:9
720 P 59.94/60 Hz 1280 720 60 Hz 74.25 MHz 16:9
576 I 50 Hz 4:3 720 576 50 Hz 13.5 MHz 4:3
576 I 50 Hz 16:9 720 576 50 Hz 13.5 MHz 16:9
480 I 59.94/60 Hz 720 480 60 Hz 13.5 MHz 4:3
576 P 50 Hz 4:3 720 576 50 Hz 27 MHz 4:3
576 P 50 Hz 16:9 720 576 50 Hz 27 MHz 16:9
480 P 59.94/60 Hz 720 480 60 Hz 27 MHz 16:9
480 P 59.94/60 Hz 720 480 60 Hz 27 MHz 4:3
