HIKVISION DS-K1201AEF User Manual

Fingerprint and Card Reader User Manual
6
2.2 Definition of Cable
The description of 5 cables is shown below.
Table 1-3 Description of Cables
Color
Description
Blue
RS-485 -
Yellow
RS-485 +
Red
PWR (DC +12V)
Black
GND (Power Grounding)
Black
GND (RS-485 Grounding)
2.3 Wiring Cables
Purpose:
Wire the cables between the controller and the card reader, thus to
establish the communication between them.
Steps for RS-485 communication mode:
1. Set the DIP switch for RS-485 address. For Details, refer to
2.1 Introduction for DIP Switch.
2. Wire the cable between the controller and the card reader
as shown below.

HIKVISION DS-K1201AEF Specifications

General

Brand	HIKVISION
Model	DS-K1201AEF
Category	Card Reader
Language	English
