HIKVISION DS-K1T804EF User Manual

Fingerprint Access Control Terminal·User Manual
89
 The lower-level organizations will be deleted as well if you delete an organization.
 Make sure there is no person added under the organization, or the organization cannot be
deleted.
5.6 Person Management
After adding the organization, you can add person to the organization and manage the added
person such as issuing cards in batch, importing and exporting persons information in batch, etc.
Note: Up to 10,000 persons or cards can be added.
5.6.1 Adding Person
Adding Person (Basic Information)
Steps:
1. Select an organization in the organization list and click Add button on the Person panel to pop
up the adding person dialog.
2. The Person No. will be generated automatically and is not editable.
3. Input the basic information including person name, gender, phone No., birthday details, and
email address.
4. Click Upload Picture to select the person picture from the local PC to upload it to the client.
Note: The picture should be in *.jpg format.

HIKVISION DS-K1T804EF Specifications

General

Type	Intelligent access control reader
Log capacity	100000
Product color	Black
Cards capacity	3000 cards
Fingerprint reader	Yes
Authentication type	Access chip/card, Biometric
Keypad number of keys	18
False Rejection Rate (FRR)	0.01 %
False Acceptance Rate (FAR)	0.001 %
Contactless working distance	50 mm
Front camera	No
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
PC connection	RS-485/USB 2.0/Wi-Fi
Display type	TFT-LCD
Display diagonal	2.4 \
Maximum resolution	320 x 240 pixels
DC current (max)	2 A
DC voltage range	12 - 12 V

Weight and Dimensions

Depth	37 mm
Width	76.5 mm
Height	205 mm
