HIKVISION DS-KD8002-VM Quick Start Guide

Video Intercom Door Station·Quick Start Guide
28
4.3 Edit Network Parameters
Purpose:
Network connection is mandatory for the use of door station.
Steps:
5. Go to the configuration mode.
1) Hold down the * key and the # key for 2s to enter the admin password page.
2) Enter the admin password, and press the # key.
Figure 4-3 Admin Password Page
The default admin password is 888999.
6. Enter the network parameters settings page.
1) Press the numeric keys 4 and 6 to switch to the network configuration page.
Figure 4-4 Network Configuration Page
2) Press the # key to enter the network parameters settings page.
With the private SIP protocol, you should set IP address, sub mask, gateway, SIP IP,
main IP, and center IP for the door station.

HIKVISION DS-KD8002-VM Specifications

General

Video codecs	H.264
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
Number of buttons	14 buttons
Connectivity technology	Wired
Sustainability certificates	RoHS
Voice codecs	G.711u
Operating system installed	Linux
Proper use	Outdoor
Product color	Aluminium, Black
Outdoor unit housing material	Aluminum
International Protection (IP) code	IP65
Display diagonal	3.5 \
Display resolution	480 x 320 pixels
Display technology	LCD/TFT
Display aspect ratio	3:2
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	1
Operating relative humidity (H-H)	10 - 90 %
Door station operating temperature (T-T)	-40 - 70 °C
Outdoor unit power type	AC/DC
Power consumption (typical)	15 W
Sensor type	CMOS
Maximum frame rate	30 fps
Maximum video resolution	1280 x 720 pixels

Weight and Dimensions

Depth	61 mm
Width	145 mm
Height	418 mm
Door station dimensions (WxDxH)	145 x 61 x 418 mm
