HIKVISION DS-KD8102-V User Manual

Video Intercom Door Station·User Manual
67
Adding by IP Address/IP Segment
Steps:
1. Click the Manual button to open the device adding window.
2. Enter the corresponding information (IP address, user name, password, start IP
address, end IP address).
3. Click the Add button.
Figure 8-41 Adding by IP Address/IP Segment
8.6.2 Upgrading Devices
Door station supports upgrading by file.
Upgrading by File: You upgrade the device or devices via the local upgrade files.
Steps:
1. Select a device or multiple devices, and select “Upgrade by File” as the upgrading
mode.
2. Click to pop up the window for opening the upgrading file.

HIKVISION DS-KD8102-V Specifications

General

Color	Yes
Video codecs	H.264
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
Number of buttons	14 buttons
Connectivity technology	Wired
Sustainability certificates	RoHS
Proper use	Outdoor
Product color	Black
Outdoor unit housing material	Plastic
International Protection (IP) code	IP65
Voice codecs	G.711u
Display diagonal	3.5 \
Display resolution	480 x 320 pixels
Display technology	LCD/TFT
Display aspect ratio	3:2
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	1
Operating system installed	Linux
Operating relative humidity (H-H)	10 - 90 %
Door station operating temperature (T-T)	-40 - 70 °C
Outdoor unit power type	AC/DC
Power consumption (typical)	15 W
Megapixel	1.3 MP
Sensor type	CMOS
Maximum frame rate	30 fps
Maximum video resolution	1280 x 720 pixels

Weight and Dimensions

Depth	61 mm
Width	145 mm
Height	418 mm
Door station dimensions (WxDxH)	145 x 61 x 418 mm
