Video Intercom Indoor Station·User Manual
45
Figure 8-32 Zone Settings Interface
2. Select a zone type from the drop-down list menu.
3. Select an alarm mode from the drop-down list menu.
4. Set the zone status: NO or NC.
5. Set the enter delay.
6. Set the exit delay.
7. Click the Apply button to enable zone settings.
 Six zone types are supported: Emergency Switch, Door Magnetic Switch, Smoke
Detector, Active IR Detector, Passive IR Detector, and Combustible Gas Detector.
 Three types of alarm mode are supported: Instant Alarm, 24H Alarm, and Delay
Alarm.
 When the zone type is set to be Instant Alarm, only under arming mode, the indoor
station will receive alarm message when the detector is triggered. Under disarming
mode, it will not receive alarm message when the detector is triggered.
 When the zone type is set to be 24H Alarm, the indoor station will receive alarm
message when the detector is triggered no matter it is under arming mode or
disarming mode.
 When the zone type is set to be Delay Alarm, only under arming mode, the indoor
station will receive alarm message when the detector is triggered. Under disarming
mode, it will not receive alarm message when the detector is triggered.
 After setting enter delay time, if the OK button is pressed within the enter delay time
after the alarm, the alarm event will not be uploaded to the management center; if
the OK button is not pressed within the enter delay time after the alarm, the alarm
event will be uploaded to the management center.
 The exit delay is the time between you enable the arming mode and the arming takes
effect.
 The DS-KH6201(L) and DS-KH6310-W(L) only support 2 zones.
IP Camera Information
Purpose:
You can add, delete and modify network IP cameras with two ways of getting stream:
direct or URL. You can also import and export the IP camera information.

HIKVISION DS-KH8301-WT Specifications

General

Color	Yes
Video codecs	H.264
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
Connectivity technology	Wired
Sustainability certificates	RoHS
Voice codecs	G.711u
Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Display technology	LCD/TFT
Proper use	Indoor
Control type	Touch
Product color	White
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, RTSP
Outdoor unit included	No
Operating system installed	Linux
Operating relative humidity (H-H)	10 - 90 %
Main monitor station operating temperature (T-T)	-10 - 55 °C
Indoor unit power type	AC/DC
Power consumption (typical)	10 W
Megapixel	0.3 MP
Sensor type	CMOS
Maximum frame rate	30 fps
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB

Weight and Dimensions

Depth	26 mm
Width	217 mm
Height	142 mm
