Figure 3-6 Wall Mounng
3.4 Table Mounng
Steps
1.
Wiring the device and smooth the cables across the cable hole.
Figure 3-7 Smooth the Cable
2.
Adjust the table bracket to the right angle and put the device on the right
posion.
Figure 3-8 Adjust the Table Bracket
Note
Recommend the use of the table bracket: the maximum opening angle used.
Video Intercom Main Staon Operaon Guide
10
