(2) Use an impact drill to drill holes on the installation holes with a depth of about
120mm; for the 3 racetrack holes at the bottom
(3) Insert the expansion bolts with a diameter of 12mm into the installation holes, and
tighten the nuts to fix them.
3. Cable Connection
This equipment is equipped with a special terminal block, and all wiring needs to be
completed on the terminal block.
(1) Trigger mode wiring:
