HIKVISION HiLook IPC-B120H-U User Manual

Network Bullet Camera·Quick Start Guide
15
Note:
Drill the cable hole, if adopting ceiling outlet to route the cable.
3-Φ 4 mm
Cable Hole
Side
Opening
Screw Hole
template
Φ 55 mm
Φ 68 mm
Φ 18 mm
Figure 2-2 The Drill Template
3. Route the cables through the cable hole (optional), or the side
opening.
4. Fix the camera on the ceiling/wall with supplied screws.
