Network Video Recorder User Manual
66
6.4.3 Other Events
Thermal Camera Detection
The device supports the event detection modes of thermal network cameras: fire detection,
temperature detection, etc. You can configure the arming schedule and linkage actions of the
selected event.
Before You Start
Add a thermal network camera to your device and make sure the camera is activated.
Steps
1. Go to Configuration → Event → Other Events.
2. Select a thermal camera detection event.
3. Set Camera.
4. Set the arming schedule. Refer to Configure Arming Schedule for details.
5. Set the linkage actions. Refer to Configure Alarm Linkage Action for details.
6. Click Apply.
6.4.4 Configure Arming Schedule
Steps
1. Click Arming Schedule.
2. Choose one day of a week and set the time segment. Up to eight time periods can be set within
each day.
Note
Time periods shall not be repeated or overlapped.
Figure 6-25 Set Arming Schedule
3. Click Apply.
