HIKVISION HiLook Series User Manual

SMART LIGHT
LIGHT
THRESHOLD
LEVEL
BACK
EXIT
SAVE & EXIT
AUTO
2
5



Figure 3-6 SMART LIGHT
 AUTO
Under the AUTO mode, the white light turns on
automatically as the environment becomes dark.
The THRESHOLD is the environmental light level at
which the white light turns on. The greater the value is,
the darker the environment should be to activate the
light.
The value of LEVEL controls the brightness of the white
light. The greater the value is, the brighter the light is.
 OFF
The white light is always off except when alarm is set
and triggered.
3.5 FACTORY DEFAULT
Reset all the settings to factory defaults.
3.6 EXIT
Move the cursor to EXIT and click Iris+ to exit the menu.
3.7 SAVE & EXIT
Move the cursor to SAVE & EXIT and click Iris+ to save
the settings and exit the menu.
UD23821B-A

HIKVISION HiLook Series Specifications

General

Power Supply	12 VDC
Video Compression	H.264/H.265
Analog Video Input	Depends on model
CVBS Input	Depends on model
Video Output	HDMI/VGA
Audio Compression	G.711
Audio Input	Depends on model
Audio Output	Depends on model
Two-Way Audio	Depends on model
Hard Disk	SATA
Capacity	Up to 10TB (depends on model)
Network Interface	RJ45 10M/100M
USB Interface	USB 2.0
Consumption	Depends on model
Working Temperature	-10 °C to 55 °C (14 °F to 131 °F)
Dimensions	Depends on model
Weight	Depends on model
HDTVI Input	Depends on model
AHD Input	Depends on model
HDCVI Input	Depends on model
IP Video Input	Depends on model
