Network Traffic Camera • User Manual
50
Set Traffic Light Synchronization
Go to Configuration> Device Configuration > Capture Parameters > Traffic Light
Synchronization.
Set Traffic Light Synchronization
Check Enable Traffic Light Synchronization, to adjust the device phase position in sync.
with that of flash light.
Enter Phase Position to adjust flash light brightness. It ranges from 0 to 360.
Select Signal Frequency according to actual power supply frequency.
Click Save to save the settings.
Set Image Composition
A group of composed images can give direct evidence to the illegal driving actions. Set the image
composition on this page.
Go to Configuration> Device Configuration > Capture Parameters > Image Composition.
Image Composition
Check Enable Composition.
Select the composition method. Click the Option box, and select the composition method
from the pop-up dialog box.
