HIKVISION iVMS-4200

Network Camera User Manual
35
Figure 5-3 PTZ Control Panel
Click the zoom/focus/iris buttons to realize lens control.
Notes:
 There are eight direction arrows ( , , , , , , , ) in the control
panel. Click the arrows to realize adjustment in the relative positions.
 For the cameras which support lens movements only, the direction buttons are
invalid.
Table 5-2 Descriptions of PTZ Control Panel
Icon
Description
Zoom in/out
Focus near/far
Iris +/-
PTZ speed adjustment
Light on/off
Wiper on/off
Auxiliary focus
Initialize lens
Adjust speed of pan/tilt movements
Start Manual Tracking
Setting/Calling a Preset
 Setting a Preset:
1. In the PTZ control panel, select a preset number from the preset list.
