EURO 46 V10 Programming Manual
No. Output Type Active Restore
0034 Lights When the exit or entry timer starts. 20 seconds after the set/unset procedure has
completed.
0035 Follow Input • Active when a specific input number has been activated. It allows the following options to
be programmed:
• Follow Type (Follow, Timed, Latched, Code Reset);
• Follow What (Input, Shunt List, Sub-Area, Area);
• Follow When (Always, When Armed, When Disarmed);
• Input to Follow
0036 Shunt Fault After an input in the shunt list is opened with an active detector (attempting to un-shunt) the ‘Shunt
Fault’ output pulses until the shunt is reset.
0037 Restore 1 At code entry to set. The normal state of this
input is 0v and it changes to 12v when activated.
After three seconds.
0038 Restore 2 Activates whenever an additional area is set. The
normal state of this input is 0v and it changes to
12v when activated.
When unset.
0039 PIR Latch 1 When set (and in Walk Test). At alarm, or when unset.
0040 PIR Latch 2 This is the inverse polarity to PIR Latch 1. At alarm, or when unset.
0041 Mains Good Output showing the 230v mains supply is present.
0042 Detr Indn Enable Output activates during walk test and also when a code is entered to view detector indications
(staying activated for the time that indications are viewed).
0043 Follow Test Output will activate only when tested from the Engineer menu ‘Test Outputs’ in the ‘Engineer Tests’.
This output can be used as an additional facility for testing the operation of a Bell. An output
programmed to one of these configurations (43 and 44) may be used to trigger a relay to break the
hold-off connection to the Bell – or even to provide the hold-off directly.
0044 Off During Test Output is normally active and will deactivate only when tested from the Engineer menu ‘Test
Outputs’ in the ‘Engineer Tests’ (the same as 43 but opposite activation).
0048 Detr Walk Test This output is active during walk test and will only deactivate when all detectors have been tested.
0049 Detector Masked If any detector goes into ‘mask’ condition the
output will activate.
When the masking fault clears.
0050 Follow 24 Hour If any input programmed as ‘24 Hour’ activates. When the input is restored.
0051 Comms Fault When the Telephone / Network or GPRS Line
Fault is present.
When the fault clears.
0052 Mains Fail After the pre-set time without mains power. Upon restoration of mains.
0053 Battery Fault When the battery is disconnected or load fail is
detected.
At the next valid code entry.
0054 Low Volts When less than 11.2v are present. When the fault clears.
0055 Global Fault 1
Grade 2)
Activates if any fault occurs (only when the
system is set).
When all faults are cleared.
0056 Global Fault 2
(Grade 3)
Activates if any fault occurs (at any time). When all faults are cleared.
0057 German Relay For future development. DO NOT USE.
0058 Guard Code Used When ‘guard’ code is used on the system After 60 seconds.
0059 Engineer Access When entering Engineer mode. When leaving Engineer mode.
0060 Initialise Digi At power up. Live for 45 seconds.
0063 Test ATE/GSM Activates when a test call is sent. When the test is completed.
0064 Test ATS. For use
with ATE complying
with BSIA Form 175
to initiate test call
to ARC by each
available path.
Test signalling through PSTN and GSM. Activates
when a test call is sent.
When the test is completed.
