EURO 46 V10 Programming Manual
No. Output Type Active Restore
0065 Zone Activity Fault This is the output that will activate in response to the ‘Monitor Activity’ Input, once the programmed
NAT time has elapsed. It will be cleared / restored by the next valid code entry.
0066 ATE Not Used Makes the ATE pin 5V or 0V depending on whether ATE outputs are inverted.
0170-
-0199
User Defined 01-30 The user outputs are used for user automation to control external devices. They can be controlled
via the keypad from the user menu and can be programmed as ‘latched’ or ‘timed’ (1 to 99 sec).
No. Output Type
0202 Hold Up A (As 0002 for Area A )
0203 Intruder A (As 0003 for Area A )
0204 Final Set A (As 0004 for Area A )
0206 Confirmed A (As 0006 for Area A)
0207 Tamper A (As 0007 for Area A )
0208 Duress A (As 0008 for Area A )
0209 HU Device A (As 0009 for Area A )
0210 Fire Reset A (As 0010 for Area A )
0213 Secure Int A (As 0013 for Area A )
0214 Siren A (As 0014 for Area A)
0216 Strobe A (As 0016 for Area A )
0217 Omit At Reset/rearm A (As 0017 for Area A )
0218 Unconfirmed A (As 0018 for Area A )
0219 Can Set A (As 0019 for Area A )
0220 Exit Starts A (As 0020 for Area A )
Then this pattern repeats for all other areas other areas so that:
0222-0240 Area B 0242-0260 Area C 0262-0280 Area D 0282-0300 Area 0 0302-0320 Area 1
0600-0609 Timers 01-10: For future development
0610-0619 Calendar 01-20: For future development
0620-0639 UDL Programmable Logic Gates 1-20.
0640-0649 Delay 01-10: For future development
1001-1046 Active when input opened and close when input is closed
*The use of pulsed or latched key-switch will make the system unable to comply with EN50131-1
