Symbols
4 Affinity® Three Birthing Bed and Affinity® Four Birthing Bed User Manual (USR025 REV 6)
Foot and head sections Up/Down controls
Seat section mattress control (optional). A through D model beds.
Seat section mattress control (optional). E model and newer beds.
TV On/Off/Audio control (optional). A through D model beds.
TV On/Off/Audio control (optional). E model and newer beds.
CPR function—Identifies the release lever that can be used to manu-
ally drop the inclined head section, in order that cardiopulmonary
resuscitation can be performed without delay. A through D model
beds.
CPR function—Identifies the release lever that can be used to manu-
ally drop the inclined head section, in order that cardiopulmonary
resuscitation can be performed without delay. E model and newer
beds.
Lockout control label—The switch in the up position indicates the
lockout control is on. The switch in the down position indicates the
lockout control is off (refer to the section titled “Lockout Controls” on
page 20 for lockout status information). A through D model beds.
