Hilti PMC 46 User Manual

ORIGINAL OPERATING INSTRUCTIONS
PMC 46 combilaser
It is essential that the operating instructions
are read before the tool is operated for the
first time.
Always keep these operating instructions
together with the tool.
Ensure that the operating instructions are
with the tool when it is given to other
persons.
Contents Page
1. General information 13
2. Description 14
3. Accessories 15
4. Technical data 16
5. Safety instructions 17
6. Before use 18
7. Operation 18
8. Care and maintenance 21
9. Troubleshooting 21
10. Disposal 22
11. Manufacturer’s warranty 23
12. EC declaration of conformity 23
1 These numbers refer to the corresponding illustra-
tions. The illustrations can be found on the fold-out
cover pages. Keep these pages open while studying
the operating instructions.
In these operating instructions, the designation “the
tool” always refers to the PMC 46 combilaser.
Parts, operating controls and indicators 1
@
On-button
;
LED
=
Pendulum
%
Removable foot
&
Back of the tool
1. General information
1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that could lead
to serious bodily injury or fatality.
WARNING
Draws attention to a potentially dangerous situation
that could lead to serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation
that could lead to slight personal injury or damage to
the equipment or other property.
NOTE
Draws attention to an instruction or other useful
information.
1.2 Explanation of the pictograms and other
information
Warning signs
General
warning
en
13

Hilti PMC 46 Specifications

General

Laser Class	Class 2
Self-leveling Range	±5°
Operating Temperature Range	-10°C to +50°C
Battery Life	20 h
IP Protection Class	IP54
Battery Type	AA Batteries
