PMC 46
Laser visibility glasses PUA 60 The laser visibility glasses are not
protective glasses and thus do not
protect the eyes from laser beams.
As the laser visibility glasses
restrict color vision, they should
be worn only when working with
this tool. Do not wear the laser
visibility glasses while driving a
vehicle on a public road.
4. Technical data
Right of technical changes reserved.
Range of the points 30 m (98 ft)
Range of the lines and intersection point 10 m (30 ft)
Accuracy of the points Distance 10 m (30 ft): ±3 mm (±¹/₈ in)
Accuracy of the laser lines Length of the lines 10 m (30 ft): ±1.5 mm (±¹/₁₆ in)
Self-leveling time
3s
Laser class
Class 2, visible, 635 nm, ±10 nm (EN 60825-3:2007
/ IEC 60825 - 3:2007); class II (CFR 21 §1040 (FDA)
Beam diameter Distance 5 m: < 4 mm
Distance 20 m: < 16 mm
Line width Distance 5 m: < 2.2 mm
Self-leveling range
±5° (typical)
Automatic power-off Activated after: 15 min
Operating status indicator
LED and laser beams
Power supply AA‑size batteries, Alkaline batteries: 4
Battery life (2 points and 1 line) Alkaline battery 2,500 mAh, Temperature +25°C
(+77°F): 20 h (Typical)
Operating temperature range Min. -10°C / Max. +50°C (+14 to 122°F)
Storage temperature Min. -25°C / Max. +63°C (-13 to 145°F)
Dust and water spray protection (except battery
compartment)
IP 54 as per IEC 529
Tripod thread (tool)
UNC¹⁄₄"
Tripod thread (foot) BSW 5/8 "UNC¹⁄₄"
Weight
with the foot but without batteries: 0.413 kg ( 0.911
lbs)
Dimensions
with the foot: 140 mm X 73 mm X 107 mm
without the foot: 96 mm X 65 mm X 107 mm
en
16

Hilti PMC 46 Specifications

General

Laser Class	Class 2
Self-leveling Range	±5°
Operating Temperature Range	-10°C to +50°C
Battery Life	20 h
IP Protection Class	IP54
Battery Type	AA Batteries
