English 5
3.6 Charging status display on the PSA 82 battery when charging with the PSA 85 charger
PSA 82
PSA 85
The charging LED can have the following statuses:
Status Meaning
1 LED lights green. • The battery is fully charged.
1 LED lights orange. • The battery is charging.
1 LED lights red. • State of charge: < 25 %
3.7 Charging status display on the PSA 86 charger
PSA 86
Status Meaning
1 LED lights red. • The battery is charging.
1 LED lights green. • The charger is in working order.
1 LED blinks red • The battery is fully charged.
1 LED blinks green • The charger or the battery is not in working
order.
The error message can have the following causes:
• Voltage too high
• Short circuit
• Voltage too low
• Temperature is outside the charging temperature range
• Electronic fault
Note
If the battery is not recognized by the charger, this may indicate that the battery is defective. In this
case, the battery can no longer be charged and only the green LED on the charger lights when the
battery is inserted. To obtain a replacement battery, please contact Hilti Customer Service.
4 Technical data
4.1 Battery technical data
PSA 80 PSA 81 (01 and 02) PSA 81 (05)
Type
NiMH Liion Liion
Rated voltage
9.6 V 7.4 V 7.4 V
Operating voltage
•/• 6 V …8.4 V 6.5 V …8.4 V
Input voltage
•/• 12 V 12 V …19 V
Capacity
2,000 mAh 5,200 mAh 5,000 mAh
Charging time
3 h 3 h 3 h
IP protection class
54 56 56
Operating temperature
0 ℃ …40 ℃
(32 ℉ …104 ℉)
−15 ℃ …50 ℃
(5 ℉ …122 ℉)
−20 ℃ …50 ℃
Storage temperature (dry)
•/• −25 ℃ …60 ℃
(−13 ℉ …140 ℉)
−20 ℃ …50 ℃
(−4 ℉ …122 ℉)
Charging temperature
0 ℃ …30 ℃
(32 ℉ …86 ℉)
0 ℃ …40 ℃
(32 ℉ …104 ℉)
0 ℃ …40 ℃
(32 ℉ …104 ℉)
Printed: 29.09.2017 | Doc-Nr: PUB / 5070488 / 000 / 07
