2.3 Switches
Control switch with electronic speed control
2-speed gear selector switch
Forward / reverse selector switch with safety lock
Torque and drilling mode setting ring
2.4 Grips
Vibration-absorbing grip
2.5 Lubrication
Grease lubrication
2.6 The items supplied include (toolbox versions):
1 Power tool
1 Operating instructions
1 Hilti toolbox
2.7 The items supplied include (cardboard box versions):
1 Power tool
1 Operating instructions
2.8 Additional items required for operating the tool
B 14/3.3 or B 14/1.6 Liತion battery with C 4/36, C 4/36ತACS or C 4/36ತACS TPS battery charger.
2.9 Li-ion battery charge status and overheating indicator
LEDs light constantly LEDs blink Charge status C
LED 1,2,3,4
-
C ฺ 75 %
LED 1,2,3
-
50 % ู C < 75 %
LED 1,2
-
25 % ู C < 50 %
LED 1
-
10 % ู C < 25 %
-
LED 1
C < 10 %
-
LED 1 Battery overheated
2.10 Overload and overheating protection
The power tool is equipped with an electronic protection system to prevent overloading and overheating. The
power tool switches itself off automatically in the event of overloading and overheating. After releasing the
control switch, the power tool may not restart immediately when the switch is pressed again (while the power
tool is cooling down).
3. Insert tools, accessories
Bit holder
S-BH 50
Charger for Li-ion batteries C 4/36
Charger for Li-ion batteries C 4/36ತACS
Charger for Li-ion batteries C 4/36-ACS TPS
Battery B 14/3.3, B 14/1.6
Belt hook (optional)
Keyless chuck clamping range 1.5…13 mm
Drilling diameter range in wood (soft)
1.5…20 mm
Drilling diameter range in wood (hard) 1.5…12 mm
Drilling diameter range in metal 1.5…10 mm
Wood screws (max. length 80 mm) 3…6 mm
Driving screws in plastic anchors (max. length
120 mm)
Max. 8 mm
4. Technical data
Right of technical changes reserved.
Power tool SFC 14ತA
Rated voltage (DC voltage)
14.4 V
Weight in accordance with EPTA procedure 01/2003 1.5 kg
Dimensions (L x W x H with B 14/1.6) 192 mm x 80 mm x 225 mm
Speed in 1st gear (with B 14/3.3)
0…500/min
Speed in 2nd gear (with B 14/3.3)
0…1,700/min
Torque with tool set to drilling symbol (soft/flexible
joint)
Max. 24 Nm
Torque range (15 settings) 1.5…10 Nm
NOTE
The vibration emission level given in this information sheet has been measured in accordance with a
standardised test given in EN 60745 and may be used to compare one tool with another. It may be used for a
preliminary assessment of exposure. The declared vibration emission level represents the main applications of
the tool. However if the tool is used for different applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly increase the exposure level over the total working
period. An estimation of the level of exposure to vibration should also take into account the times when the
tool is switched off or when it is running but not actually doing the job. This may significantly reduce the
exposure level over the total working period. Identify additional safety measures to protect the operator from
the effects of vibration such as: maintain the tool and the accessories, keep the hands warm, organisation of
work patterns.
