10 English
Push the battery into the tool from the rear until it engages with an audible click.
5.2 Removing the battery
Remove the battery.
5.3 Fitting the accessory tool
1. Set the forward/reverse switch to the middle position or remove the battery from the power tool.
2. Check that the connection end of the accessory tool is clean. Clean the connection end if necessary.
3. Open the keyless chuck.
4. Insert the accessory tool into the keyless chuck and then turn the chuck firmly by hand until tight and
several clicks are heard.
5. Check that the accessory tool is held securely.
5.4 Removing the accessory tool
1. Set the forward/reverse switch to the middle position or remove the battery from the power tool.
2. Open the keyless chuck.
3. Pull the accessory tool out of the keyless chuck.
5.5 Switching on
Press the control switch.
Speed can be controlled steplessly right up to maximum by varying how far the control switch is
pressed in.
Printed: 11.09.2018 | Doc-Nr: PUB / 5152681 / 000 / 04

Other manuals for Hilti SFC 14-A

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hilti SFC 14-A and is the answer not in the manual?

Hilti SFC 14-A Specifications

General IconGeneral
Number of gears2
Screw diameter (max)8 mm
Sound pressure level69 dB
Idle speed (1st gear)1700 RPM
Drilling diameter in wood (max)20 mm
Drilling diameter in steel (max)10 mm
Vibration level (metal drilling)2 m/s²
Maximum torque (hard applications)45 N⋅m
Maximum torque (soft applications)24 N⋅m
Product colorBlack, Red
Chuck typeKeyless
Product designPistol grip drill
Number of batteries included1 pc(s)
Power sourceBattery
Battery voltage14 V
Weight and Dimensions IconWeight and Dimensions
Weight1500 g
