Hilti SFC 14-A User Manual

English 11
5.6 Switching off
▶ Release the control switch.
5.7 Drilling
1.
Set the torque and operating mode selector ring to the symbol.
2. Set the forward/reverse switch to the “forward” position.
5.8 Screwdriving
1. Set the torque and operating mode selector ring to the required torque.
2. Set the forward/reverse switch to the desired direction of rotation.
5.9 Setting forward or reverse rotation
An interlock prevents switching while the motor is running.
The control switch is locked when the forward/reverse switch is in the middle position (safety lock).
▶ Set the forward/reverse switch to the desired direction of rotation.
5.10 Selecting the gear
▶ Select the gear.
Printed: 11.09.2018 | Doc-Nr: PUB / 5152681 / 000 / 04

Hilti SFC 14-A Specifications

General

Number of gears	2
Screw diameter (max)	8 mm
Sound pressure level	69 dB
Idle speed (1st gear)	1700 RPM
Drilling diameter in wood (max)	20 mm
Drilling diameter in steel (max)	10 mm
Vibration level (metal drilling)	2 m/s²
Maximum torque (hard applications)	45 N⋅m
Maximum torque (soft applications)	24 N⋅m
Product color	Black, Red
Chuck type	Keyless
Product design	Pistol grip drill
Number of batteries included	1 pc(s)
Power source	Battery
Battery voltage	14 V

Weight and Dimensions

Weight	1500 g
