3 Description
3.1 Product overview 1
@
1/4" hex socket
;
Torque and drilling mode se-
lector ring
=
Gear speed selection switch
%
Forward/reverse selector
switch with safety lock
&
Grip
(
Fitting slot for accessories
(fig.: Belt hook)
)
Lamp
+
Charge status display
§
Battery release button
/
Control switch (with electronic
speed control)
:
Adapter
3.2 Intended use
The product described is a hand-held cordless drill / driver for driving and
removing screws, drilling in metal, wood and plastic. The product has an
interchangeable chuck and can be fitted with various adapters.
• Use only Hilti Li-ion batteries of the B 12 series with this product.
• Use only Hilti-approved battery chargers to charge these batteries. More
information is available from your Hilti Store or from: www.hilti.group
3.3 Items supplied
Drill / driver, operating instructions
Other system products approved for use with this product can be found
at your local Hilti Store or online at: www.hilti.group
3.4 Charge state display
The charge state of the Liion battery is displayed after pressing one of the
release buttons lightly (press only until slight resistance is felt).
Status Meaning
4 LEDs light. Charge state: 75 % to 100 %
3 LEDs light. Charge state: 50 % to 75 %
2 LEDs light. Charge state: 25 % to 50 %
1 LED lights. Charge state: 10 % to 25 %
1 LED blinks. Charge state: < 10 %
Battery charge state cannot be displayed while the control switch is
pressed and for up to 5 seconds after releasing the control switch.
3.5 Overload and overheating protection
The power tool is equipped with an electronic system to protect against
overloading and overheating. The power tool switches itself off automatically
