Hilti TE 7-C User Manual

2.2 Chucks
TE‑C CLICK chuck
2.3 Switches
Speed control switch for smooth starting.
Function selector switch:
Drilling without hammering
Hammer drilling
Chisel adjustment (18 positions)
Chiseling
2.4 Grips
Vibration-absorbing, pivotable side handle with depth gauge
Vibration-absorbing grip
2.5 Protective feature
Mechanical slip clutch
2.6 Lubrication
Oil lubrication
2.7 Items supplied as standard
1 Power tool
1TE‑C CLICK chuck
1 Side handle with depth gauge
1 Operating instructions
1 Hilti toolbox
1 Cleaning cloth
1 Grease
2.8 Using extension cords
Use only extension cords of a type approved for the application and with conductors of adequate cross section.
The power tool may otherwise loose performance and the extension cord may overheat. Check the extension
cord for damage at regular intervals. Replace damaged extension cords.
Recommended minimum conductor cross section and max. cable lengths
Conductor cross sec-
tion
1.5 mm² 2.5 mm² 3.5 mm² 14 AWG 12 AWG
Mains voltage 100V 50 m
Mains voltage 110-
120 V
30 m 50 m
100 ft 150 ft
Mains voltage 220-
240 V
75 m 100 m
Do not use extension cords with 1.25 mm² or 16 AWG conductor cross sections.
en
3

Hilti TE 7-C Specifications

General

Impact energy (max)	2.6 J
Sound pressure level	89 dB
Vibration level (hammer drilling)	17 m/s²
Drilling diameter in concrete (max)	16 mm
Reverse	Yes
Power source	AC

Weight and Dimensions

Depth	343 mm
Width	86 mm
Height	215 mm
Weight	3400 g
