ORIGINAL OPERATING INSTRUCTIONS
TE 80‑ATC/ TE 70‑ATC/ TE 70 combihammer
It is essential that the operating instructions
are read before the power tool is operated
for the first time.
Always keep these operating instructions
together with the power tool.
Ensure that the operating instructions are
with the power tool when it is given to other
persons.
Contents Page
1. General information 17
2. Description 18
3. Insert tools, accessories 20
4. Technical data 20
5. Safety instructions 22
6. Before use 25
7. Operation 25
8. Care and maintenance 27
9. Troubleshooting 28
10. Disposal 29
11. Manufacturer’s warranty - tools 30
12. EC declaration of conformity 30
1 These numbers refer to the corresponding illustra-
tions. The illustrations can be found on the fold-out
cover pages. Keep these pages open while studying
the operating instructions.
In these operating instructions, the designation “the
power tool” always refers to the TE 80-ATC / TE
70-ATC / TE 70 combihammer.
Operating controls and indicators 1
@
Function selector switch
;
Control switch lock
=
Control switch
%
Supply cord
&
Power reduction button (50% power)
(
Side handle
)
Chuck
+
Insert tool lock
§
Theft protection indicator (option)
/
Service indicator
:
Reduced power indicator
1. General information
1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that could lead
to serious bodily injury or fatality.
WARNING
Draws attention to a potentially dangerous situation
that could lead to serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation
that could lead to slight personal injury or damage to
the equipment or other property.
NOTE
Draws attention to an instruction or other useful
information.
1.2 Explanation of the pictograms and other
information
Warning signs
General
warning
Warning:
electricity
Warning: hot
surface
en
17
