2.11 Using extension cords
Recommended minimum conductor cross section and max. cable lengths
Conductor cross section 1.5 mm² 2mm² 2.5 mm² 3.5 mm²
Mains voltage 100V 30 m 50 m
Mains voltage 110-120 V 20 m 30 m 40 m
Mains voltage 220-240 V 30 m 75 m
2.12 Using a generator or transformer
This power tool may be powered by a generator or transformer when the following conditions are fulfilled:
The unit must provide a power output in watts of at least twice the value printed on the type identification
plate on the power tool. The operating voltage must remain within +5% and -15% of the rated voltage at all
times, frequency must be in the 50 – 60 Hz range and never above 65 Hz, and the unit must be equipped with
automatic voltage regulation and starting boost.
Never operate other power tools or appliances from the generator or transformer at the same time. Switching
other power tools or appliances on and off may cause undervoltage and / or overvoltage peaks, resulting in
damage to the power tool.
3. Insert tools, accessories
Hammer drill bits Ø 12…45 mm
Breach bits Ø 40…80 mm
Percussion core bits Ø 45…150 mm
PCM diamond core bits
Ø 42…132 mm
Chisels Pointed, flat and shaped chiselswithTE‑Y connection
end
Wood drill bits Ø 10…32 mm
Metal drill bits Up to Ø 20 mm
TPS theft protection system with company card,
company remote and TPS‑K key
Option, 206999
Setting tool Setting tool with TE‑Y connection end , 32221
Quick-release chuck Keyless chuck for wood and metal drill bits with
smooth or hex. shank, 60208, Chuck holder 263359
Mixing paddles for non-flammable materials, with
smooth or hex. shank
Ø 80…150 mm, 41215 (Ø80mm), 41216
(Ø110mm), For use only with the keyless quick-
release chuck
4. Technical data
Right of technical changes reserved.
Power tool TE 80‑ATC TE 70‑ATC TE 70
Weight in accordance
with EPTA procedure
01/2003
10.2 kg 8.9 kg 7.7 kg
en
20
