TE905-AVR breaker
1. General information
1.1 Signal words and their meaning
-CAUTION-
Used to draw attention to a potentially dangerous situa-
tion which could lead to minor personal injury or dam-
age to the equipment or other property.
-NOTE-
Used to draw attention to an instruction or other useful
information.
1.2 Pictograms
Contents Page
1. General information 11
2. Description 12
3. Tools and accessories 12
4. Technical data 13
5. Safety precautions 13
6. Before use 15
7. Operation 15
8. Care and maintenance 17
9. Troubleshooting 17
10. Disposal 18
11. Warranty 18
12. EC declaration of conformity 19
Operating controls and components
Chuck
On/off switch
Grip
Side handle
Side handle clamp
Screw
Service indicator
Activation indicator (theft protection system)
(available as option)
Supply cord
Ventilation slots
These numbers refer to the corresponding illustra-
tions. The illustrations can be found on the fold-out cover
pages. Keep these pages open while studying the oper-
ating instructions.
In these operating instructions, the TE905-AVR breaker
is referred to as "the tool".
Location of identification data on the tool
The type designation and serial number can be found on
the rating plate on the tool. Make a note of this data in
your operating instructions and always refer to it when
making an enquiry to your Hilti representative or service
department.
Type: TE905-AVR
Serial no.:
Warning signs
General
warning
Warning:
electricity
Warning:
hot surface
Obligation signs
Wear
a safety
helmet
Wear
breathing
protection
Wear
ear
protection
Wear
protective
gloves
Wear
eye
protection
Read the
operating
instructions
before use.
Symbols
Equipped with
theft protection
system
