General information
In these operating instructions, this symbol indi-
cates points of particular importance to safety. The
instructions at these points must always be observed in
order to avoid the risk of serious injury.
Electrical (CAUTION)
This symbol warns of hazards as a result of the electri-
cal current when using the tool. It marks a dangerous
situation. The illustrated behavior following this symbol
must always be observed in order to avoid serious injury
or damages to property.
The numbers refer to the illustrations. The illustra-
tions can be found on the fold-out cover pages. Keep
these pages open while you read the operating instruc-
tions.
In these operating instructions, the TE6-A with battery
is referred to as “the tool”.
The following conditions must always be observed
when the tool is in use:
– The tool is for hand-held use only.
– Do not use the tool in places where the surrounding
conditions may present a risk of explosion.
It is essential that the operating
instructions are read before the
tool is operated for the first time.
Always keep these operating
instructions together with the tool.
Ensure that the operating instruc-
tions are with the tool when it is
given to other persons.
Contents Page
General information 1
Technical data 2
General safety rules 3
Specific safety rules and Symbols 4
Functional description 4
Assembly 5
Operation 5
Maintenance 6
Accessoires 6
Warranty 7
Diposal 7
Operating controls
Chuck
Side handle with depth gauge
Selector switch for hammering action / rotary only
Forwards / reverse switch and transport lock
Battery (accessory, not supplied with the tool)
Control switch
TE6-A cordless rotary hammer
