HIMA HIMatrix F30 Engineering Manual

HI 800 101 HIMatrix Engineering Manual
1 Certification
The safety-related HIMA HIMatrix programmable controllers (Programmable Electronic Sys-
tems, PES) are tested and certified by TÜV for functional safety in accordance to
and the
standards listed below:
TÜV Anlagentechnik GmbH
Automation, software and information technology
Am Grauen Stein
51105 Köln
Certificate and test report No. 968/EZ 128.14/07
Safety-related automation devices
HIMatrix F60, F20, F35, F31, F30, F3 DIO 20/8 01, RIO-NC
International standards:
IEC 61508, Teile 1-7: 2000
IEC 61511: 2004
EN 954-1: 1996
EN ISO 13849-1:2006
EN 62061:2005
EN 12067-2: 2004, EN 298: 2003, EN 230: 1990
EN 61131-2: 2003
EN 61000-6-2: 2001, EN 61000-6-4: 2001
NFPA 85: 2007
NFPA 86: 2007
NFPA 72: 2002
F 60 und F35: EN 54-2: 1997
National standards:
DIN VDE 0116: 1989, EN 50156-1:2004
Chapter 9 Operating Conditions contains a detailed listing of all applied environment and
EMC tests.
All devices are labeled with the sign.
To program of the HIMatrix devices, a PADT (programmer unit, PC) running the program-
ming tool
ELOP II Factory
and the program languages Function Block Diagram (FBD) and Sequential Function Chart
(SFC) in accordance to IEC 61131-3 is used. This software assists the user in creating safe-
ty-related programs and operation of the PES.
8 of 61
