HIMA HIMatrix F30 Engineering Manual

HI 800 101 HIMatrix Engineering Manual
9.4 Voltage Supply
The most important tests and limit values for the voltage supply of the equipment are listed in
the following table:
IEC/EN 61131-2
Chapter 6.3.7
Verification of DC Power Supply Characteristics
The power supply must meet alternatively the following
standards:
IEC/EN 61131-2 or
SELV (Safety Extra Low Voltage) or
PELV (Protective Extra Low Voltage)
The fusing of the HIMatrix devices must be in accor-
dance to the statements of this manual
6.3.7.1.1
Voltage range test:
24 VDC, -20 %...+25 % (19.2 V...30.0 V)
6.3.7.2.1
Momentary interruption immunity test:
DC, PS 2: 10 ms
6.3.7.4.1
Reversal of DC power supply polarity test:
application note in the according chapter of the system
manual or in the data sheet of power supply module
6.3.7.5.1
Backup duration withstand test:
Test B, 1000 h, Lithium battery is used for backup
61 of 61
