HIMA HIMatrix F30 User Manual

System Manual Compact Systems 7 Start-Up
HI 800 141 E Rev. 2.02 Page 53 of 110
Parameter
Description
Default
value
Setting for safe
operation
Max.Com. Time
Slice ASYNC [ms]
Highest value in ms for the time slice used for
communication during a resource cycle, see the
communication manual (HI 801 101 E),
2...5000 ms
60 ms
Application-
specific
Max. Duration of
Configuration
Connections [ms]
Only applicable with F*03 devices/modules!
It defines how much time within a CPU cycle is available
for process data communication, 2...3500 ms
6 ms
Application-
specific
Maximum System
Bus Latency [µs]
Not applicable for HIMatrix controllers!
0 µs
-
Allow Online
Settings
ON:
All the switches/parameters listed below OFF
can be changed online using the PADT.
ON
OFF is
recommended
OFF:
These parameters may
not be changed online
 System ID
 Autostart
 Global Forcing
Allowed
 Global Force
Timeout Reaction
 Load Allowed
 Reload Allowed
 Start Allowed
These parameters may
be changed online if
Reload Allowed is set
to ON.
 Watchdog Time (for
the resource)
 Safety Time
 Target Cycle Time
 Target Cycle Time
Mode
If Reload Allowed is set
to OFF, they are not
changeable online.
i
Allow Online Settings can only be set to ON if
the PES is stopped.
Autostart
ON:
If the processor module is connected to the
supply voltage, the user program starts
automatically
OFF
Application-
specific
OFF:
The user program does not start automatically
after connecting the supply voltage.
Start Allowed
ON:
A cold start or warm start permitted with the
PADT in RUN or STOP
ON
Application-
specific
OFF:
Start not allowed
Load Allowed
ON:
Configuration download is allowed
ON
Application-
specific
OFF:
Configuration download is not allowed
Reload Allowed
Only applicable with F*03 devices/modules!
ON
Application-
specific
ON:
Configuration reload is allowed
OFF:
Configuration reload is not allowed.
A running reload process is not aborted when
switching to OFF
Global Forcing
Allowed
ON:
Global forcing permitted for this resource
ON
Application-
specific
OFF:
Global forcing not permitted for this resource
Global Force
Timeout Reaction
Specifies how the resource should behave when the global
force timeout has expired:
 Stop Forcing
 Stop the Resource
Stop
Forcing
Application-
specific
