7 Start-Up System Manual Compact Systems
Page 66 of 110 HI 800 141 E Rev. 2.02
Failures during the code generation may occur due to the non-safe PC!
For safety-related applications, the code generator must generate the code two times
and the checksums (CRCs) resulting from the two code generations must be identical.
Only if this is the case, an error-free code is ensured.
Refer to the safety manual (HI 800 023 E) for further details.
7.3.7 Configuring the System ID and the Connection Parameters
To configuring the system ID and the connection parameters
1. Select the resource in the structure tree.
2. Click the Online button located on the Action Bar or select Online on the context menu.
The System Login dialog box appears.
3. Click Search.
The Search per MAC dialog box appears.
4. Enter the MAC address valid for the controller - see the label on the housing - and click
Search.
In the dialog box, the values set for IP address, subnet mask and S.R.S are displayed.
5. If the values for the project are not correct, click Change.
The Write via MAC dialog box appears.
6. Type correct values for the connection parameters and the SRS, and enter the access data
for a user account with administrator rights valid on the controller. Click Write.
Connection data and S.R.S are configured and it is now possible to log in.
For further details, refer to the SILworX manual First Steps (HI 801 103 E).
7.3.8 Loading a Resource Configuration after a Reset
If the compact system is switched on with engaged reset key, it restarts and resets the
connections parameters and user account to the default values (only in case of a controller).
After a new restart with disengaged reset key, the original values are used.
If the connection parameters were modified in the user program, they can be configured in the
compact systems such as described in Chapter 7.3.7.
Logging in as Default User
After configuring the connection parameters and prior to loading the user program, the default
user (administrator with empty password) must be used in the following cases:
The password for the user account is no longer known.
A new user account should be used in the project.
To log in as default user
1. Select the resource in the structure tree.
2. Click the Online button located on the Action Bar or select Online on the context menu.
The System Login dialog box appears.
3. In the IP Address field, select the correct address or use the MAC address.
4. Enter Administrator in the User Group field.
5. Let the Password field empty or cancel the password.
6. Select Administrator in the Access Mode field.
7. Click Log-in.
SILworX is connected to the HIMatrix controller with default user rights.
