HI 800 101 HIMatrix Engineering Manual
100 mm
DIO
20/8 01
3
1
DIO
20/8 01
20 mm
Minimum clearances for HIMatrix Fxx and Remote I/O (Compact devices)
100 mm100 mm
234.9 mm
Minimum clearances for HIMatrix F60
Figure 1: Minimum clearances at installation
