HIMA HIMatrix Series Engineering Manual

HI 800 101 HIMatrix Engineering Manual
Modular device F60
For a detailed description of the hardware of the F60 and all applicable modules see the cor-
responding Data sheets and the System Manual Modular System F60.
Modular device Properties Interfaces
F60, GEH 01
part no.
98 2200103
Modular system housing,
freely selectable I/O modules
on CPU 01 module
Module Properties I/O range
AI 8 01
part no.
98 2200214
Analog input module 8 unipolar inputs 0...10 V,
4 bipolar inputs -10...+10 V,
with shunt 0/4...20 mA
AO 8 01
part no.
98 2200215
Analog output module 8 outputs 0...
±10 V / 0/4...20 mA
CIO 2/4 01
part no.
98 2200099
Counter module 2 counter to 1 MHz,
4 digital outputs
DI 24 01
part no.
98 2200113
Digital input module
for high voltages
24 inputs 110 VDC, 127 VAC
DI 32 01
part no.
98 2200114
Digital input module,
configurable with Line Control
32 digital inputs 24 VDC
DIO 24/16 01
part no.
98 2200100
Digital input/output module
outputs configurable as
pulsed outputs for Line Control
24 digital inputs 24 VDC,
16 digital outputs 24 VDC
DO 8 01
part no.
98 2200112
Digital output module with relay
outputs
8 relay contact outputs
110 VDC, 230 VAC
MI 24 01
part no.
98 2200115
Multi-input module 24 analog inputs 0/4...20 mA,
or
24 digital inputs for contacts
(with resistors) or initiators
PS 01
part no.
98 2200096
Power supply unit F60
CPU 01
part no.
98 2200126
Central module,
integrated 4 port switch
100 Base-Tx with safeethernet
4 Ethernet-Ports, integrated
switch
2 Field bus terminals
5 of 61
