HIMA HIMatrix Series Engineering Manual

HI 800 101 HIMatrix Engineering Manual
HIMatrix Product Overview
Compact devices
For detailed descriptions of the devices listed below and their specifications see the corre-
sponding Data sheets and the System Manual of the Compact Systems.
Compact device Properties Interfaces
F20
part no.
98 2200417
8 digital channels,
configurable as inputs or outputs
4 pulsed outputs for Line Control
2 Ethernet ports,
integrated switch
2 Field bus terminals
F30
part no.
98 2200415
20 digital inputs,
8 digital outputs, configurable as
pulsed outputs for Line Control
4 Ethernet ports,
integrated switch
3 Field bus terminals
F31 01
part no.
98 2200403
20 digital inputs,
8 digital outputs, configurable as
pulsed outputs for Line Control
2 Ethernet ports,
integrated switch
F31 02
part no.
98 2200420
20 digital inputs,
8 digital outputs, configurable as
pulsed outputs for Line Control
4 Ethernet ports,
integrated switch
F35
part no.
98 2200416
2 counters,
8 analog inputs 0-10 V or 0/4-20 mA,
24 digital inputs, 8 digital outputs
4 Ethernet ports,
integrated switch
3 Field bus terminals
F1 DI 16 01
part no.
98 2200405
Remote I/O module
16 digital inputs
4 pulsed outputs for Line Control
2 Ethernet ports,
integrated switch
F2 DO 4 01
part no.
98 2200408
Remote output module
4 digital power outputs up to 5 A
2 Ethernet ports,
integrated switch
F2 DO 8 01
part no.
98 2200407
Remote output module
8 relay outputs up to 250 VAC
2 Ethernet ports,
integrated switch
F2 DO 16 01
part no.
98 2200406
Remote output module
8 digital outputs up to 2 A,
8 digital outputs up to 1 A
2 Ethernet ports,
integrated switch
F2 DO 16 02
part no.
98 2200422
Remote output module
16 relay outputs up to 30 VAC
2 Ethernet ports,
integrated switch
F3 DIO 8/8 01
part no.
96 9000114
Remote output module
8 digital inputs
8 digital L+ switching outputs
2 digital L- switching outputs
2 pulsed outputs
2 Ethernet ports,
integrated switch
F3 DIO 16/8 01
part no.
96 9000112
Remote output module
16 digital inputs
8 two-pole digital outputs
2 pulsed outputs
2 Ethernet ports,
integrated switch
F3 AIO 8/4 01
part no.
98 2200409
Remote I/O module
8 analog inputs 0-10 V or 0/4-20 mA,
4 analog outputs 0/4-20 mA
2 Ethernet ports,
integrated switch
F3 DIO 20/8 01
part no.
98 2200402
Remote I/O module
20 digital inputs,
8 digital outputs, configurable as
pulsed outputs for Line Control
2 Ethernet ports,
integrated switch
multimaster-capable
F3 DIO 20/8 02
part no.
98 2200404
Remote I/O module
20 digital inputs,
8 digital outputs, configurable as
pulsed outputs for Line Control
2 Ethernet ports,
integrated switch
4 of 61
