X-CPU 01 3 Product Description
HI 801 009 E Rev. 4.00 Page 11 of 52
3.2 Scope of Delivery
The module must be installed on a suitable connector board to be able to operate. The
connector board is described in Chapter
3.6. An Ethernet cable is required to connect to the
PADT.
Connector boards and Ethernet cables are not included within the scope of delivery of the
module.
3.3 Type Label
The type label specifies the following important details:
Product name
Mark of conformity
Bar code (2D or 1D code)
Part number (Part-No.)
Hardware revision index (HW Rev.)
Software revision index (SW Rev.)
Operating voltage (Power)
Ex specifications (if applicable)
Production year (Prod-Year:)
Figure 1: Sample Type Label
