X-CPU 01 3 Product Description
HI 801 009 E Rev. 4.00 Page 19 of 52
3.4.13 Redundancy Indicators
LED Color Status Description
On
Do not remove the module!
The module is absolutely required for operating the
HIMax system. Only one module is configured.
Blinking1
Do not remove the module!
The module is absolutely required for operating the
HIMax system. Multiple redundant modules are
configured.
Ess Yellow
Off
The module is not absolutely required for operation. It
may be removed, if required.
On
The module is operating redundantly with at least one
additional module.
Blinking1
At least one processor module starts system operation
or less modules than planned are operating
redundantly.
Red Yellow
Off The module is not operating redundantly.
Table 7: Redundancy Indicators
3.4.14 System Bus Indicators
The system bus LEDs are labeled Sys Bus.
LED Color Status Description
On
Physical and logical connection to the system bus
module in slot 1.
Green
Blinking1
No physical connection to the system bus module in
slot 1.
A
Yellow Blinking1
The physical connection to the system bus module
in slot 1 has been established.
No connection to a (redundant) processor module
running in system operation.
On
Physical and logical connection to the system bus
module in slot 2.
Green
Blinking1
No physical connection to the system bus module in
slot 2.
B
Yellow Blinking1
The physical connection to the system bus module
in slot 2 has been established.
No connection to a (redundant) processor module
running in system operation.
A+B Off Off
Neither physical nor logical connection to the
system bus modules in slot 1 and slot 2.
Table 8: System Bus Indicators
